M.242 Nailing Pallet Line
(WITH 2 NAILING MACHINE TO
PRODUCE BLOCK PALLETS)
All equipment is fully customizable, contact us for more info!
The 2 different blocks are made in the 2 block cutters or, if pressed-block types, they are
unstacked automatically. Then they are automatically fed into the fist nailing machine,
where the boards for the assembly with blocks are fed, in order to produce the top of the
4-way pallet. These half-ready pallets are turned over and fed into the second nailing
machine, where the bottom part of the 4-way pallet is made by nailing the bottom boards
to skis or perimeter bases. If necessary, this pallet is then chamfered, corner-cut and
branded and then stacked, either normally or nested.
.
Product type:
4-ways pallet with block and full perimeter pallets from 24x24 to 60x60 in; CP from 1 to
9, EURO and CHEP
Production: 360-420 pallets/hr. (theoretical; it can decrease according to pallet type and
dogs distance)
Personnel:
4/5operators
Changeover time:
60/90 min.
M.242 Nailing Pallet Line
(WITH 2 NAILING MACHINE TO
PRODUCE BLOCK PALLETS)
Quick adjustment line consisting of 3-4 mechanical nailing machines. Decks and
stringer, assembly of decks onto blocks, ski-boards and perimeter boards nailing. Decks
and the upper part of the 2-way pallet are produced in the deck nailing machine and
then fed by a buffer in the second nailing machine. The 2 different blocks are made in
the 2 block cutters or automatically unstacked if they are pressed type blocks. Then they
are placed (if necessary, turned over) into the nailing machine by the feeder. Here decks
are assembled to blocks. These semi-ready pallets are then turned over, so that ski-
boards are pushed into the next machine by transversal magazines and placed under
the chucks and nailed. For example, this machine produces the bottom decks of the 2-
way pallet. In the fourth optional nailing machine, the turned over pallets are assembled
to perimeter boards. This machine has an automatic riveting system for double deck
pallets, i.e. CP 7. After this, chamfering, corner cutting, branding and stacking are
carried out.
Product Type: stringer pallet, block and full perimeter pallets from 24x24 to 60x60 in; CP
from 1 to 9, EURO and paper pallets (free positioning of deck-boards, ski-boards and
blocks).
Production: 380-480 pal./hr. (theoretical; it can decrease according to pallet type and
dogs distance, i.e. EURO = 480 pcs./h)
Personnel: 3-4 operators
Changeover time: ca. 30 min. (with paper pallet, 1/-2 minutes upon request).
M.242 Nailing Pallet Line
(TO PRODUCE DECKS AND STRINGER PALLETS)
Quick adjustment line consisting of 2 mechanical nailing machines. Decks and tops of
the Stringer pallets are produced inside the deck machine, then fed by a turn-over into
the second nailing machine to produce the bottom of the pallet. The line is completed
with chamfering and corner cutting machine, and the system to provide an either normal
or nested stacking. Line with great production output and quick changeovers.
Product Type: decks, Stringer, and Skid pallets
Production: 380-480 pallets/hr.
Personnel: 3 operators
Changeover Time: ca. 15/20 min.
M242/M246
(PAPER PALLETS TO PRODUCE NON-PERIMETER
BLOCK PALLETS)
Quick adjustment line consisting of 2 mechanical nailing machines. Decks and tops of
the Stringer pallets are produced inside the deck machine, then fed by a turn-over into
the second nailing machine to produce the bottom of the pallet. The line is completed
with chamfering and corner cutting machine, and the system to provide an either normal
or nested stacking. Line with great production output and quick changeovers.
Product Type: decks, Stringer, and Skid pallets
Production: 380-480 pallets/hr.
Personnel: 3 operators
Changeover Time: ca. 15/20 min.
AUTOMATIC FEEDING
(FOR BOARDS, BLOCKS AND
ELEMENTS FROM A STACK.)
Only 1 operator acting as supervisor.
We can offer selection scan systems to take away non-conform boards or pallets.
Boards are lifted up by a vacuum system (optional: mechanical grips or turned-over
unstacking), then they are positioned onto the chain guides, aligned and the separation
layer is removed. Then they are singularized and out of the nailing machine there is the
correct partition of deck-boards which are put into the magazine by a grip. Pressed
blocks are taken on the length side and put into the machine. Stacking with vacuum,
grip or turn-over.
M342-13
Mechanical nailing machine. Stringers are pushed by the dogs onto the chain. The 2-3 different types of deck-boards come from 2-3 magazines and are placed directly under the nailing beam by a servocontrolled pusher.
Open and closed decks can be produced; also, the distance between the deck boards can be modified.
Optional: pre-jig for various lengths and up to 5 stringers.
Product type: decks and stringer pallets from 24x24 to 59x59 in (optional 12 - 98 in)
Production: GMA 500 pallets/hr. (theoretical); CP1 325 pcs. /hr. (theoretical).
Personnel: 1-2 operators Changeover time: 5-10 min. (30 sec. - 2 min. Auto Changeover)
M242-5
Upper and lower board entry joins two pieces.
Available in 4 sizes for solid and corrugated board. Production speed up to 7,000 boxes per hour.
M246-13
Semi Auto Collector Option
M242-5
Automatic and Independent End of Line Collector
(Click Machines For More Details)
