Riveting/Bordering Machines for Pliable
Boxes
All equipment is fully customizable, contact us for more info!
Bordering Machine M.164B
Bordering Machine M.173
Riveting M.215
Corner connection elements are produced, bordered and bent in the machine M164.
The 2 wood sides are positioned together with the corner connection in the machine
M215 and fixed pneumatically. Once it has been programmed, the machine rivets
automatically these elements together until the whole frame of the pliable box is ready.
Product type: frames of pliable boxes. Max. height 64 in, width and length at will.
Production: 20-60 frames/hr. according to box size (theoretical; it can decrease
according to box type). Personnel: 1 operator
Changeover time: 5-10 minutes.
Stitching Machines for Wood Boxes
M369 Boxcutter
M.236 Boxcutter
M369 for corner elements sizes 1.6x1.6 in, length 2.4 x 24 in. 4 corners at the same time.
M.236 for boxcutting
MM.287 Boxcutter
M.203 Automatic Stitcher
MM.287 2 lanes. Production up to 9.000 pcs./hr.
M203 automatic. Production up to 4.200 pieces/hr.
M311
M302 Stitcher
M311 stitching line for corners with up to 3+3 and 5+5 stitching heads. Control of stitching head by
servomotor. Here you can integrate machines M319 and M302.
M302 production up to 4.200 pcs/hr. with 4 stitching heads
M271
M250
M271 bottom magazine
M250 to feed boards.
Machines to produce woodboxes for fruit and vegetables totally automatised production
plants with quick adjustment (i.e. M203, with a production of about 4.000 pcs/hr.)
Production can reach up to a maximum of 4.000 pcs/hr. (theoretical; it can decrease
according to the woodbox type). Besides, we offer all necessary machines to produce a
full wood-box for fruit and vegetables.
Then stringers are cut to length and cut in two corner parts. In the stitching machine for
front sides, short sides of the woodbox are produced; then they are stitched together
with the side boards in the frame stitching machine. The bottom is produced separately
and then stitched to the frame by a corner stitch. You can produce low woodboxes with
one board only and high woodboxes with up to 3 boards.
Lines:
M203: 4.200 pcs. /hr. +/- 15% (theoretical; it depends on
quantity of stitches).
Box sizes: 7.8x11.8 up to 16x24 in, height 2.4-12 in
M295
M70
M295 line to produce small baskets for bread, fruit and vegetables.
M70 flat stitch for small baskets.
