Pallet Wireframes
All equipment is fully customizable, contact us for more info!
Pallet Wireframes
All equipment is fully customizable, contact us for more info!
Stringer
Quick adjustment line consisting of 2 mechanical nailing machines. Decks and tops of
the Stringer pallets are produced inside the deck machine, then fed by a turn-over into
the second nailing machine to produce the bottom of the pallet. The line is completed
with chamfering and corner cutting machine, and the system to provide an either normal
or nested stacking. Line with great production output and quick changeovers.
Stringer
Quick adjustment line consisting of 2 mechanical nailing machines. Decks and tops of
the Stringer pallets are produced inside the deck machine, then fed by a turn-over into
the second nailing machine to produce the bottom of the pallet. The line is completed
with chamfering and corner cutting machine, and the system to provide an either normal
or nested stacking. Line with great production output and quick changeovers.
Block
Only 1 operator acting as supervisor.
We can offer selection scan systems to take away non-conform boards or pallets.
Boards are lifted up by a vacuum system (optional: mechanical grips or turned-over
unstacking), then they are positioned onto the chain guides, aligned and the separation
layer is removed. Then they are singularized and out of the nailing machine there is the
correct partition of deck-boards which are put into the magazine by a grip. Pressed
blocks are taken on the length side and put into the machine. Stacking with vacuum,
grip or turn-over.
Block
Only 1 operator acting as supervisor.
We can offer selection scan systems to take away non-conform boards or pallets.
Boards are lifted up by a vacuum system (optional: mechanical grips or turned-over
unstacking), then they are positioned onto the chain guides, aligned and the separation
layer is removed. Then they are singularized and out of the nailing machine there is the
correct partition of deck-boards which are put into the magazine by a grip. Pressed
blocks are taken on the length side and put into the machine. Stacking with vacuum,
grip or turn-over.
Combo
Quick adjustment line consisting of 3-4 mechanical nailing machines . Decks and
stringer, assembly of decks onto blocks, ski-boards and perimeter boards nailing. Decks
and the upper part of the 2-way pallet are produced in the deck nailing machine and
then fed by a buffer in the second nailing machine. The 2 different blocks are made in
the 2 block cutters or automatically unstacked if they are pressed type blocks. Then they
are placed (if necessary, turned over) into the nailing machine by the feeder. Here decks
are assembled to blocks. These semi-ready pallets are then turned over, so that ski-
boards are pushed into the next machine by transversal magazines and placed under
the chucks and nailed. For example, this machine produces the bottom decks of the 2-
way pallet. In the fourth optional nailing machine, the turned over pallets are assembled
to perimeter boards. This machine has an automatic riveting system for double deck
pallets, i.e. CP 7. After this, chamfering, corner cutting, branding and stacking are
carried out.
Combo
Quick adjustment line consisting of 3-4 mechanical nailing machines . Decks and
stringer, assembly of decks onto blocks, ski-boards and perimeter boards nailing. Decks
and the upper part of the 2-way pallet are produced in the deck nailing machine and
then fed by a buffer in the second nailing machine. The 2 different blocks are made in
the 2 block cutters or automatically unstacked if they are pressed type blocks. Then they
are placed (if necessary, turned over) into the nailing machine by the feeder. Here decks
are assembled to blocks. These semi-ready pallets are then turned over, so that ski-
boards are pushed into the next machine by transversal magazines and placed under
the chucks and nailed. For example, this machine produces the bottom decks of the 2-
way pallet. In the fourth optional nailing machine, the turned over pallets are assembled
to perimeter boards. This machine has an automatic riveting system for double deck
pallets, i.e. CP 7. After this, chamfering, corner cutting, branding and stacking are
carried out.
